ME1004 Brush-Type DC Motor

ME1004 Brush-Type DC Motor
Item# ME1004

Product Description

This is a Permanent Magnet, Brush Type, DC Motor with Neodymium Iron Boron Magnets. The 1" shaft is similar to the shaft on most Lawn and Garden Tractor engines. This motor is perfect for an engine replacement on a Lawn and Garden tractor when converting the tractor to electric propulsion. No motor control is necessary for an engine-swap, but you will need to add a Contactor, Fuse, and 48 VDC batteries. Capable of 200 amps continuous, and 400 amps for 30 seconds. The peak efficiency is 88%.

ME1004 Outline Drawing
ME1013 Brush Holder Kit
ME1013 Brush Holder Kit
Brush Holder Kit for the ME1003, ME1008, ME1007, and ME1004 motors. Comes with 16 new brushes fully assembled, and 16 new springs. Easy to replace by removing the 4 Phillips Head screws on the black steel cover, then 4 bolts M5 that hold the Brush Holder to the aluminum base.
$99.00
ME1013
