ZYT42-04 56 FRAME 180VDC 1/3HP 1750RPM TEFC

ZYT42-04 56 FRAME 180VDC 1/3HP 1750RPM TEFC
Item# ZYT42-04
$159.00

Product Description

Brush-type, 56-frame DC motor rated at 180 VDC, 1/3 HP and 1750 RPM. Continuous rated current of 1.7 amps and 12 Lb-In of torque. Shaft diameter of 5/8 inch with a 3/16 inch keyway. Totally Enclosed Fan Cooled (TEFC). Class F insulation system and 56C-face and foot mounts. UL Listed, File E477489. Similar to Leeson 098005.
