ZYT48-20 56 FRAME 180VDC 1HP 1750RPM TEFC

ZYT48-20 56 FRAME 180VDC 1HP 1750RPM TEFC
Item# ZYT48-20
$224.00

Product Description

Brush-type, 56-frame DC motor rated at 180 VDC, 1 HP and 1750 RPM. Continuous rated current of 5 amps and 36 Lb-In of torque. Shaft diameter of 5/8 inch with a 3/16 inch keyway. Totally Enclosed Fan Cooled (TEFC). Class F insulation system and 56C-face and foot mounts. UL Listed, File E477489. Similar to Leeson 108023.
