ZYT42-07 56 FRAME 90VDC 3/4HP 1750RPM TEFC

ZYT42-07 56 FRAME 90VDC 3/4HP 1750RPM TEFC
Item# ZYT42-07
$196.00

Product Description

Brush-type, 56-frame DC motor rated at 90 VDC, 3/4 HP and 1750 RPM. Continuous rated current of 7.6 amps and 27 Lb-In of torque. Shaft diameter of 5/8 inch with a 3/16 inch keyway. Totally Enclosed Fan Cooled (TEFC). Class F insulation system and 56C-face and foot mounts. UL Listed, File E477489. Similar to Leeson 098032.
